Mechanical properties for decisive wall thickness: ≤ 30 mm.
For thickness> 30 mm, consult us.
Type of cast iron | Standard | Grades | Traction | Elasticity | Elongation A % | HB Hardness |
---|---|---|---|---|---|---|
Spheroidal graphite cast iron SPHÄROGUSS |
NF EN 1563 DIN |
EN GJS 400-15 EN GJS 400-18 EN GJS 400-18LT EN GJS 400-18RT EN GJS 450-10 EN GJS 500-7 EN GJS 600-3 EN GJS 700-2 EN GJS 450-18 EN GJS 500-14 EN GJS 600-10 GGG 40-3 |
400 400 400 400 450 500 600 700 450 500 600 400 |
250 250 240 250 310 320 370 420 350 400 470 250 |
15 18 18 18 10 7 3 2 18 14 10 18 |
135-180 130-175 130-175 130-175 160-210 170-230 190-270 225-305 170-200 185-215 200-230 130-180 |
Lamellar graphite cast iron Grauguss - |
NF EN 1561 |
EN GJL 150 EN GJL 200 EN GJL 250 - |
150 200 250 300 |
- - - - |
- - - - |
150-210 170-230 190-250 - |
Alloy cast iron |
Upon request ni-hard / ni-resist / chromium alloy cast iron |
